Troubleshooting

Issue

I was trying to login to vSphere Client at was hit with Error Connecting ‘A general system error occurred: Authorize Exception’

Lovely, great description I thought, checked all the VMware services and VMware vCenter Site Recovery Manager Server service wasn’t started, so being a logical chap, I started it and restarted VMware VirtualCenter Server.  Still no joy Error Connecting ‘A general system error occurred: Authorize Exception’

Next, I tried using a different account to login, same issue.  Ah ha, I thought let me jump onto the vSphere Web Client and see if that worked. Nope, this time I got another error

‘The authentication server returned an unxpected error: ns0:RequestFailed: Failed to connect to identify source.  Possible reasons include invalid user name or password, connection refusal, connection timeout, or failure to resolve hostname.  The error may be caused by a malfunctioning identity source’.

This was a little more descriptive, and it was time to look at SSO.

Resolution

It is important to understand that Single Sign On is ‘the’ identity source’ for everything vCenter related.  Having had a couple of issues in the past I had remembered to use the following credentials to login:

admin@system-domain

password

admin

Once logged in go to Sign On & Discovery > Configuration > Identity Sources and you should see the Active Directory Identity Source.  When I tested connection I was getting ‘probing for connectivity failed’

Bit of digging around checking DNS, Reverse DNS settings I finally found out that original Domain Controllers had been decomissioned with some shiny new ones.

One of the things when you edit the Identity Source configuration, the changes don’t actually amend, I have heard rumours that you can delete the whole line tab out and try again, but for me I had to delete and recreate the Identity Source.  This process entails:

1. Remove YourDomain.Local from Default Domains
2. Delete Active Directory Identity Source

Once done recreate you Active Directory Identity Source, I ran into an issue where Reuse Session just wouldn’t work, in the end I opted for Password instead, once finished it looked like this.

TOP TIP: Make Sure You Save The Changes To Default Domain By Click The Disk Icon

Login to the vSphere Web Client was now working which was awesome, however when I was trying to access the vSphere Client, I received another error ‘Cannot complete login due to an incorrect user name or password’

To be fair, this took me a while to resolve until something clicked.  On the Active Directory Identity Source, I had left the Domain Alias blank (didn’t take a screenshot) but the great news is this cannot be edited!

So I created another Active Directory Identity Source this time with a Domain Alias and voila I was able to login with to the vSphere Client again.

Lessons Learnt

1. Check to make sure that your Domain Controllers haven’t been decommissioned.
2. Ensure you have your admin@system-domain password
3. Changes to Identity Source don’t work in the GUI, create a new one.
4. Make sure you enter a Domain Alias in your Identity Source

As part of my day job, I review vSphere infrastructures giving recommendations on areas which could be potential concerns.  Many of the business’s that I see engaged consultants to perform the initial installation and configuration and hand vCenter/vSphere back to the internal IT department.  Overtime, changes are made and settings are updated without consideration to what they mean.

So with this in mind, I decided to put together this blog post ’10 Things To Check Quickly in vCenter’

1. Admission Control

The whole point of admission control is to ensure that you have the redundancy within your infrastructure to tolerate a failure of some description, more often than not this is N+1.  So check your admission control is first of all enabled and secondary it is set correctly e.g. 2 x ESXi Hosts should be 50% CPU and 50% Memory

I have seen countless installations where this has been turned off to enable an new VM’s to be ran and the hosts where never upgraded to compensate for this increase in workload.

2. DAS Isolation Address

The default setting is a single isolation address which is your default gateway.  What happens if this goes down in a vSphere 4.1 environment? Well man down is the reaction!  Ensure that you specify numerous IP address, I commonly go for:

1. Layer 2 switch IP address used for vMotion/FT

2. SAN management IP address

3. LAN/Management  default gateway IP Address

3. VM Monitoring

Turn this on, I know the default is disabled, but that’s not an excuse.  Why wouldn’t you want vSphere to monitor your VM’s and restart them if it has no network or datastore activity?

4. VM Restart Priority

Let’s start with the premise that not all virtual machines are equal.  If you have virtualised Domain Controllers you would want these to be high priority restarts, followed by SQL and then application servers that connect to SQL.  I wrote a blog post on this a while back click me.

Take a few minutes and check with your server team to ensure that if you do have a failure then you have done your best to bring applications up in the right order.

4. DRS Rules

Spend some time working with application team creating sensible DRS Anti Affinity and Affinity rules.  Some examples are:

• Anti Affinity – Domain controllers to be running on the same ESXi host?
• Anti Affinity – SQL Cluster with RDM
• Anti Affinity – XenApp/Terminal Server farm members
• Affinity – BES and SQL

5. VMware Update Manager

I quite often see environments where VMware Update Manager hasn’t been installed and if it has you can almost guarantee that the ESXi Hosts/VM/vApp haven’t been patched.

Without being flippant, there is a reason my VMware release patches/updates which is generally for bug fixes or security issues.

6. Alerting

Check to make sure that you have a valid SNMP/SMTP server setup, as after infrastructure migrations these settings can often be wrong.

Also take some time to configure alerting at ‘root’ level in vCenter to make sure they meet you business needs.  If you aren’t sure what to implement, I wrote a couple of blog posts on this subject to get you started:

Setting Up & Configuring Alarms in vCenter 5 Part 1

Setting Up & Configuring Alarms in vCenter 5 Part 2

7.  Time Configuration

Virtual Machines take there initial time settings from the ESXi host.  We all know what dramas can happen if your virtual machines are more than 15 minutes out of sync with your domain controllers.  Use your internal domain controllers as your NTP Servers for your ESXi Hosts, it stops unnecessary NTP traffic going traversing firewalls and ensures that you won’t be affected with time skew.

8. Virtual Machines With ISO’s Attached

We all pop ISO’ onto Local Storage on ESXi Hosts as it’s not taking up valuable space on our SAN.  The worse thing we can do is forget that we have them attached as if HA needs to come into action, these VM’s are going to fail.

Either check your Local Datastores on a regular basis or if you have lots of ESXi Hosts, then use tools such as PowerGUI with the VMware Management pack installed to script it.

9. Hot Add Memory/CPU

Virtual Machine workloads change over time, why cause unnecessary downtime and potential evening or weekend work for yourself? Make sure that you enable Memory and CPU Hot Add on your templates.

10. Resource Pools

The golden rule is know what you are doing with resource pools as if you go into resource contention they are going to come into play. I have seen resource pools used as containers/folders, resource pools created at cluster level to protect ‘high importance’ VM’s which result in these VM’s having less resources to use! A quick explanation of this can be found over at Eric Sloof’s site NTPRO.NL
